SECTION 1 – SAFETY PRECAUTIONS FOR SERVICING

safety_rtm1 4/95

1-1. Symbol Usage

Means Warning! Watch Out! There are possible hazards with this

procedure!

The possible hazards are shown in the adjoining symbols.

This group of symbols means Warning! Watch Out! possible ELECTRIC SHOCK, MOVING

PARTS,

and HOT P

TS hazards. Consult symbols and related instructions below for necessary

actions

to avoid the hazards.

Marks a special safety message.

Means NOTE; not safety related.

1-2. Servicing Hazards

ELECTRIC SHOCK can kill.

1. Do

not touch live electrical parts.

2. Stop

engine before testing or repairing unit unless

the procedure specifically requires an energized

unit.

3. Insulate yourself from ground by standing or

working on dry insulating mats big enough to

prevent

contact with the ground.

Do not leave live unit unattended.

5. When

testing live unit, use

the one-hand method.

Do not put both hand inside unit. Keep one

hand

free.

MOVING

ARTS can cause injury.

1. Keep

away from moving

parts such as fans, belts,

and

rotors.

2. Have only qualified people remove guards or

covers for maintenance and troubleshooting as

necessary.

3. Keep hands, hair, loose clothing, and tools away

from

moving parts.

4. Before

working on generator

, remove spark plugs

or injectors to keep engine from kicking back or

starting.

5. Block

flywheel so that it will not

turn while working

generator components.

Reinstall panels or

guards and close doors when

servicing is finished and before starting engine.

FLYING

PIECES

OF MET

AL or DIRT can

cause injury.

1. Always wear safety glasses with side shields or

face

shield during servicing.

2. Be

careful not to short metal tools, parts, or wires

together

during testing and servicing.

STATIC

ELECTRICITY

can damage parts

on circuit boards.

1. Put on grounded wrist strap BEFORE handling

boards

or parts.

2. Use proper static-proof bags to store, move, or

ship

PC boards.

ENGINE EXHAUST GASES can kill.

1. Do

not breathe exhaust fumes.

2. Use in open, well-ventilated areas, or vent

exhaust outside and away from any building air

intakes.

ENGINE FUEL can cause fire or

explosion.

1. Stop

engine before fueling.

2. Do not fuel while smoking or near sparks or

flames.

3. Do

not overfill tank; clean up any spilled fuel.

BATTERY EXPLOSION can BLIND and

INJURE.

1. Always wear a face shield when working on a

battery.

2. Stop engine before disconnecting or connecting

battery

cables.

3. Do

not allow tools to cause sparks when working

on a battery

4. Do

not use welder to charge batteries or jump

start

vehicles.

5. Observe

correct polarity (+ and –) on batteries.

BATTERY ACID can BURN SKIN.

1. Do

not tip.

Replace damaged battery

Flush eyes and skin immediately with water

STEAM AND PRESSURIZED HOT

COOLANT can burn face, eyes, and

skin.

1. Check coolant level when

engine is cold to avoid

scalding.

2. If the engine is warm and checking is needed,

steps 3 and 4.

3. Wear

safety glasses and gloves and put a rag over

cap.

4. Turn cap slightly and let pressure escape slowly

before

completely removing cap.

FALLING EQUIPMENT can cause

serious personal injury and equipment

damage.

1. Use equipment of adequate capacity to lift

components.

2. Use

a lifting eye to lift unit only

NOT running gear

gas cylinders, or any other accessories.

Securely attach components to lifting

equipment.

The symbols shown below are used throughout this manual to call attention to and identify possible

hazards. When you see the symbol, watch out, and follow the related instructions to avoid the hazard.

Only qualified persons should service, test, maintain, and repair this unit.

During servicing, keep everybody, especially children, away.
